Ultrasonic cleaning machine is widely used in the current society. To use this equipment well, we need to know the working principle of the cleaning equipment first. Here we will introduce the working principle of this equipment.

超聲波發生器發出的高頻振蕩信號，發出高頻振蕩信號是由超聲波發生器，通過換能器將高頻振蕩信號進行轉換，轉換之后成高頻機械振蕩，高頻機械振蕩傳播到介質里面，就是傳播到清洗溶劑里面。

The ultrasonic generator sends out the high-frequency oscillation signal. The high-frequency oscillation signal is generated by the ultrasonic generator. The high-frequency oscillation signal is converted into high-frequency mechanical oscillation through the transducer. The high-frequency mechanical oscillation is transmitted to the medium, that is, to the cleaning solvent.

在清洗液中超聲波疏密相間向前輻射，超聲波清洗機在清洗液中，超聲波在疏密相間的向前輻射，數以萬計的直徑為50-500μm 的微小氣泡由于液體流動產生，在聲場的作用下，存在于液體中的微小氣泡產生振動。在超聲波縱向傳播的負壓區這些氣泡形成、快速的生長。

In the cleaning solution, the forward radiation of ultrasonic wave in the dense phase, and the forward radiation of ultrasonic wave in the dense phase of ultrasonic cleaning machine in the cleaning solution, tens of thousands of diameter is 50-500 μ Because of the liquid flow, the tiny bubbles in the liquid vibrate under the action of sound field. In the negative pressure region of ultrasonic longitudinal propagation, these bubbles form and grow rapidly.

超聲波清洗機正壓區，當達到一定值聲壓時，迅速增加氣泡，突然發生閉合。沖擊波在氣泡閉合時產生，上千個大氣壓在其周圍產生，不溶性污物被破壞，于清洗液中分散，清洗件凈化的目的就達到了。

When the positive pressure zone of ultrasonic cleaning machine reaches a certain sound pressure, bubbles increase rapidly and close suddenly. The shock wave is generated when the bubble is closed, and thousands of atmospheres are generated around it. The insoluble dirt is destroyed and dispersed in the cleaning solution. The purpose of cleaning parts is achieved.


超聲波清洗機在使用的過程中，總是不可避免的會出現受損，我們要盡量的避免這樣的情況出現，盡量避免造成損失。

Ultrasonic cleaning machine in the use of the process, will always inevitably appear damaged, we should try to avoid such a situation, try to avoid losses.

在超聲波清洗機使用過程中，如果想要減少對產品的損壞，可以選擇合適的頻率，如果頻率比較合適，功率合適，根據清洗的物件調整好合適的功率，這樣是可以很好的減少對產品的損壞的，要選擇比較合適的清洗液溫度，一般使用堿性清洗液，溫度需要控制在75度是比較合適的，當然有些物件對于溫度、清洗劑都是有要求的，我們要適當調整，不能統一水溫，適合這種物件的水溫，并不一定所有的物件都適合。而且根據清洗物件的多少，使用的清洗劑量也是不一樣的。

In the process of using the ultrasonic cleaning machine, if you want to reduce the damage to the product, you can choose the appropriate frequency. If the frequency is more appropriate and the power is appropriate, you can adjust the appropriate power according to the object to be cleaned. In this way, you can reduce the damage to the product. You should choose a more appropriate temperature of the cleaning fluid, and generally use alkaline cleaning fluid, It's more appropriate to control the temperature at 75 degrees. Of course, some objects have requirements for temperature and cleaning agent. We need to adjust the temperature appropriately. We can't unify the water temperature. The water temperature suitable for this kind of object may not be suitable for all objects. And according to the number of cleaning objects, the amount of cleaning used is not the same.

所以，想要很好的使用這個設備，就要先知道清洗設備的工作原理，希望能幫到大家。

Therefore, if you want to use this equipment well, you need to know the working principle of the cleaning equipment first. I hope it can help you.
